Direct Import
Seamlessly bring geometry and loads directly from your superstructure model.
AI + Non Linear Finite Element
Software for Structural Design
of Foundation Systems
By integrating advanced numerical methods and artificial intelligence, Foundaxis enables a powerful structural design workflow for the complete structural design of foundation systems for any building, residential, industrial, or commercial.
Welcome to a new era in Structural Design!
Export loads & Locations of the Structural Model
AI-Powered Structuring
Smart foundation layouts automatically generated based on wall and pillar distribution.
Dimensional Optimization
Optimized sizing for all foundation types under soil limit states and multiple load combinations
Steel Reinforcement Design
Automatically design steel reinforcements for all foundation types according to ACI-318 standards.
Geotechnical Analysis
Accurately predict pressure distribution and settlements in complex, multi-layered soils.
Export options
Generate complete calculation reports, structural plans, and BIM-ready models for REVIT/TEKLA with a single click.
Trusted by engineers worldwide
Join thousands of engineers building the future with our platform
Users
0
Engineers building with our tools every day
Countries
0 +
Global reach across continents and cultures
Projects
0
Foundation systems designed
Import data directly from your prefered Structural Software
Import Algorithms
FOUNDAXIS has implemented algorithms to directly read the export files from the most popular structural calculation software or alternatively personalized data set using Excel spreadsheets.
Communication between the structural model of your building and FOUNDAXIS is extremely fast.
Automatic Optimized Design and Detailed Results
FOUNDAXIS optimizes the dimensional design and designs the structural reinforcement of the foundations, whether rectangular, strip or foundation slabs. FOUNDAXIS algorithms consider nonlinear behavior in all types of foundations, for high biaxial loads that cause uplift.
A detailed analysis of the complete system is carried out, verifying compliance with the design according to its evaluation parameters. For the design, FOUNDAXIS considers admissible static and dynamic pressures and minimum required support percentage.
Multiple load combinations are considered, and the design considers all of them at the same time.
It is possible to edit the achieved design to specific project requirements such as eccentricities or fixed dimensions.
Pressure Bulb Interaction and
Settlement Analysis
Ground Analysis
FOUNDAXIS calculates the behavior of the ground under the foundation seal, determining global and differential settlements, instant and by consolidation as well as the interaction of pressure bulbs for the complete foundation system.
Complete Documentation,
Calculation Report, Design Drawings
and BIM Model
Export options
FOUNDAXIS generates a report fo all the calculations and verifications carried out, which is configured by the user and can be exported to Word or PDF.
Design plans are generated, according to the chosen configuration, which can be directly exported
in DXF format.
Additionally, the full structural model can be exported in BIM format, ready for integration with REVIT or TEKLA.
Optimize Your Foundation
Design in Minutes
Streamline your foundation design with FOUNDAXIS. Get automated calculations, detailed reports and easy exports - all in minutes. Start now and simplify your design process.
Get Started
